Sirio GP 87-108 LB/U
€95.00
Sirio GP 87-108 LB/U Base Antenna (U Connector)
- Type: 1/4λ ground plane large band
• Frequency range: RADIO band 87-108 MHz @ SWR ≤ 2.5
• Impedance: 50Ω
• Radiation (H-plane): 360° omnidirectional
• Radiation (E-plane): beamwidth @ -3 dB = 78°
• Radiation angle: 0°
• Polarization: linear vertical
• Gain: 0 dBd, 2.15 dBi
• Max. Power (CW) @ 30°C: 1000 Watts
• Grounding protection: All metal parts are DC-grounded, the inner conductor shows a DC short
• Connector: PL-female
- Materials: Anodized aluminium, Stainless steel, Nylon
• Wind resistance: 160 Km/h
• Wind load: 67 N at 150 Km/h
• Wind surface: 0.06 m²
• Height (approx).: 1190 mm
• Weight (approx.): 1500 gr
• Mounting mast: Ø 36-40 mm
