SIRIO SD 3000 U / N
€82.00
Electrical Data:
| Type: | Discone |
| Radiation: | Omnidirectional |
| Polarization: | Linear vertical |
| Frequency range: | RX band: 300-3000 MHz TX band (@ SWR ≤2): 340-535, 545-960, 1180-1380, 1660-1910, 1980-3000 MHz |
| Systems: | 70cm-HAM, TETRA-350, CDMA-450, GSM-R, GSM-900, GSM-1800, 2G-GSM/GPRS/EDGE, 3G-UMTS, 4G-LTE, ISM/SIGFOX/LoRa 868MHz, ISM/SIGFOX/LoRa 915MHz, ISM/SIGFOX/LoRa 433MHz, WiFi-2.4GHz |
| Gain: | 0 dBd – 2.15 dBi @ lowest frequency |
| Max Power: | 200 Watts (CW) continuous |
| Connector: | SD 3000 U:
UHF-female (SO-239) SD 3000 N: N-female |
Mechanical Data:
| Materials: | Chromed brass, Stainless steel, Nylon, Gold plated brass |
| Height (approx): | 725 mm / 2.38 ft |
| Weight (approx): | 830 gr / 1.83 lb |
| Mounting type: | On-Mast |
